Quick Disconnect Keyhole Plug, Environmental, 15 Position, Crimp, Socket

SKU: CBME05-15S
Distributor Quantity Buy
Contact Us
Products specifications
Attribute name Attribute value
DC Products
Series CB Series
Environmental Plug Environmental
Shell Style Plug
Termination Type PC Tail
Pins 15
Contact Type Socket
Operating Temperature -55 °C to + 85 °C
Shell Circular, Keyhole
Operating Voltage 1500 VAC
Contact Size 20/16
Size 20 Contact Amps 7.5
Size 16 Contact Amps 13
Shell Material High Grade Dielectric
Insulator Material High Temp Dielectric
Grommet Material Silicone
Contact Material Gold Plated
*
*
*
Products specifications
Attribute name Attribute value
DC Products
Series CB Series
Environmental Plug Environmental
Shell Style Plug
Termination Type PC Tail
Pins 15
Contact Type Socket
Operating Temperature -55 °C to + 85 °C
Shell Circular, Keyhole
Operating Voltage 1500 VAC
Contact Size 20/16
Size 20 Contact Amps 7.5
Size 16 Contact Amps 13
Shell Material High Grade Dielectric
Insulator Material High Temp Dielectric
Grommet Material Silicone
Contact Material Gold Plated
