SMA Male Radius R/A Connector for .085 Semi Rigid Cable

The SMA Female Jack from Amphenol CDI is engineered for reliability and precision in high-frequency signal transmission. Ideal for aerospace, defense, and telecommunications, this connector ensures consistent performance in demanding environments.

SKU: 5236-2

Distributor	Quantity	Buy

Specifications
Contact Us

Products specifications

Attribute name	Attribute value
Impedance	50 ohms
Dielectric Material	PTFE
Operating Temperature	-65°C to +125°C
Insertion Loss	.03 √f(GHz)
Frequency	18 GHz
Contact Termination	COAX, COAX
Housing Finish	Gold
Gender	Male
Body Orientation	Right Angle
RF Series	SMA
RF Connector Specifications
Hermetic	No
Body Plating	Gold
Termination	COAX
Cable Termination	.085 S/R
Center Contact Plating	Gold
Center Contact Material	BeCu
Voltage	335 Vrms max @ sea level
Mating Cycles	500 Cycles
Body Material	303 SST, 303 SST
